| Attribute | Value |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 18 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 3W |
| Output Current | 125mA |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Efficiency | 81% |
| Package | DIP 24 |
| Load Regulation | ±1% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Width | 20mm |
| Series | TEL 3 |
| Depth | 10.2mm |
| Length | 32mm |
